Products features:
Reducer of driving device for escalator is a new kind of product developed by our company. These kinds of reducers are assembled with the variable tooth worm gear sets which has obtained the national invention patent (National invention patent No. ZL00133681.9) and US patent (US Patent No. US6176148B1). They have many kinds of advantages, such as: Large loading capacity, high transmission efficiency, smooth functioning and low noise level, etc.
Products specifications:
Model | Center Distance (mm) | Ratio | Input Power (kW) | Input Speed (r/min) |
FTJ100 L/R | 100 | 49/2 | 5.5 | 960 |
FTJ125A L/R | 125 | 49/2 | 7.5-9 | 960 |
FTJ125C L/R | 125 | 55/2 | 7.5-9 | 1450 |
FTJ160G L/R | 125 | 49/2 | 8-11 | 960 |
FTJ160D L/R | 140 | 49/2 | 8-11 | 960 |
FTJ160 L/R | 160 | 49/2 | 11-15 | 960 |
FTJ180 L/R | 180 | 49/2 | 15-22 | 960 |
In the reducer model column, (L) stands for the left output shaft type, (R) stands for the right output shaft type.
